816TL

For laden container handling with straddle carriers

Product information

ELME Spreader Model 816TL is a twinlift telescopic top lift spreader for the handling of containers in twinlift mode. 816TL is designed for use with straddle carriers.

The strong and basic concept offers distinct advantages, such as two parallel telescopic beams, assuring max overlap. The beam sections are dimensioned to absorb not only the vertical, but also the very considerable horizontal forces.

Show more

Standard supply includes

Pick-up points to fit the yoke beam of the straddle carrier.
Eight vertical pendular ISO twist- locks.
Lifting eyes near twistlocks.
Hydraulic telescoping.
Show more
Type of applicationStraddle carrier
Type of lifting system8 vertical twistlocks
Spreader weight (TW)8 500 kg without extra equipment
Lifting capacity (SWL)40 tonnes +/- 10 % eccentric load
Lifting capacity (SWL)2 x 22,5 tonnes in Twinlift Mode
Lifting capacity (SWL), lifting eyes4 x 10 tonnes
Twistlock8 x ISO pendular 20 mm
Telescopic positions20, 30, 40 and 2x20ft
Telescoping speed 20-40ft< 20 sec. (calculated speed at 20° C)
Telescoping speed 40-20ft< 25 sec. (calculated speed at 20° C)
Hydraulics, operating pressure up to140 bar
Hydraulics, flow40-60 L/min
Electric - control voltage24 VDC
ColourSignal yellow RAL 1003
Paint thickness220 μ

DISCLAIMER
All specifications are subject to change without notice. A list of options enables you to adapt the product more precisely to your needs and further information is available on request.
